Precise measurement of water-quality parameters

Overview
Chlorine is an important chemical in water purification, in disinfectants and bleach products. Chlorine is also used widely in the manufacture of many products and items directly or indirectly, i.e. in paper product production, antiseptic, dyestuffs, food, insecticides, paints, petroleum products, plastics, medicines, textiles, solvents, and many other consumer products.
Free chlorine, chlorine dioxide or total chlorine (incl. chloramines) are usually measured to monitor and control the disinfection of drinking water, reuse water or pool water. When chlorine is added to water, it reacts with organic materials and metals, forming combined chlorine. Because combined chlorine is not available for disinfection, this effect is called the chlorine demand of the water.
Free chlorine
Refers to chlorine that is present as hypochlorous acid (HOCl) or the hypochlorite (OCl–) ion. For applications where the free chlorine concentration is critical for disinfection, the most robust measurement technique is the use of an amperometric free chlorine sensor.
FCL
Chlorine sensor with membrane-covered, 4 – 20 mA output and integrated automatic temperature compensation. Guaranteed precision and short response time control thanks to active amperometric measurement. Suitable for the measurement of free inorganic chlorine at constant pH or with reduced pH dependence and for free chlorine on the basis of iso-cyanuric acid (organic free chlorine). Ideal for drinking water, waste water treatment, process water and swimming pool. Also seawater.
FCL HP
Sensor for the measurement of free inorganic chlorine with open measuring cell, 4 – 20 mA output and integrated automatic temperature compensation. Guaranteed precision and short response time control thanks to active amperometric measurement. Suitable for the measurement of free inorganic chlorine at high pressure (up to 8 bar). Ideal for drinking water, waste water treatment, process water and swimming pool. Also seawater.
Chlorine dioxide
Is a neutral chlorine compound. One of the most important qualities of chlorine dioxide is its high-water solubility, especially in cold water. Chlorine dioxide is approximately 10 times more soluble in water than chlorine. It is not affected by pH and has an excellent residual effect remaining active for hours to days. It does not interact with ammonia or ammonium.
Chlorine dioxide is one of the most effective disinfection methods measurements in the water industry today. These measurements ensure effective use of chlorine dioxide for disinfection purposes as well as other applications. Under dosage can be ineffective and overdosage results in excess Chlorite by product formation. It is extremely effective in controlling legionella.
DCL
Chlorine sensor with membrane-covered, 4 – 20 mA output and integrated automatic temperature compensation. Guaranteed precision and short response time control thanks to active amperometric measurement. Suitable for drinking water and swimming pool.
DCL HP
Sensor for the measurement of chlorine dioxide with open measuring cell, 4 – 20 mA output and integrated automatic temperature compensation. Guaranteed precision and short response time control thanks to active amperometric measurement. Suitable for the measurement of free inorganic chlorine at high pressure (up to 8 bar). Ideal for drinking water, waste water treatment, process water and swimming pool. Also seawater.
Total Chlorine
Total chlorine is the combination of the free chlorine left in the water and the combined chlorine. Total chlorine sensors are commonly used in wastewater treatment plants to measure the effluent water's disinfection status.
TCL
Chlorine sensor with membrane-covered, 4 – 20 mA output and integrated automatic temperature compensation. Guaranteed precision and short response time control thanks to active amperometric measurement. Suitable for drinking water and swimming pool. Also sea water.
Free chlorine, chlorine dioxide or total chlorine (incl. chloramines) are usually measured to monitor and control the disinfection of drinking water, reuse water or pool water. When chlorine is added to water, it reacts with organic materials and metals, forming combined chlorine. Because combined chlorine is not available for disinfection, this effect is called the chlorine demand of the water.
Free chlorine
Refers to chlorine that is present as hypochlorous acid (HOCl) or the hypochlorite (OCl–) ion. For applications where the free chlorine concentration is critical for disinfection, the most robust measurement technique is the use of an amperometric free chlorine sensor.
FCL
Chlorine sensor with membrane-covered, 4 – 20 mA output and integrated automatic temperature compensation. Guaranteed precision and short response time control thanks to active amperometric measurement. Suitable for the measurement of free inorganic chlorine at constant pH or with reduced pH dependence and for free chlorine on the basis of iso-cyanuric acid (organic free chlorine). Ideal for drinking water, waste water treatment, process water and swimming pool. Also seawater.
FCL HP
Sensor for the measurement of free inorganic chlorine with open measuring cell, 4 – 20 mA output and integrated automatic temperature compensation. Guaranteed precision and short response time control thanks to active amperometric measurement. Suitable for the measurement of free inorganic chlorine at high pressure (up to 8 bar). Ideal for drinking water, waste water treatment, process water and swimming pool. Also seawater.
Chlorine dioxide
Is a neutral chlorine compound. One of the most important qualities of chlorine dioxide is its high-water solubility, especially in cold water. Chlorine dioxide is approximately 10 times more soluble in water than chlorine. It is not affected by pH and has an excellent residual effect remaining active for hours to days. It does not interact with ammonia or ammonium.
Chlorine dioxide is one of the most effective disinfection methods measurements in the water industry today. These measurements ensure effective use of chlorine dioxide for disinfection purposes as well as other applications. Under dosage can be ineffective and overdosage results in excess Chlorite by product formation. It is extremely effective in controlling legionella.
DCL
Chlorine sensor with membrane-covered, 4 – 20 mA output and integrated automatic temperature compensation. Guaranteed precision and short response time control thanks to active amperometric measurement. Suitable for drinking water and swimming pool.
DCL HP
Sensor for the measurement of chlorine dioxide with open measuring cell, 4 – 20 mA output and integrated automatic temperature compensation. Guaranteed precision and short response time control thanks to active amperometric measurement. Suitable for the measurement of free inorganic chlorine at high pressure (up to 8 bar). Ideal for drinking water, waste water treatment, process water and swimming pool. Also seawater.
Total Chlorine
Total chlorine is the combination of the free chlorine left in the water and the combined chlorine. Total chlorine sensors are commonly used in wastewater treatment plants to measure the effluent water's disinfection status.
TCL
Chlorine sensor with membrane-covered, 4 – 20 mA output and integrated automatic temperature compensation. Guaranteed precision and short response time control thanks to active amperometric measurement. Suitable for drinking water and swimming pool. Also sea water.
Features
FCL
Free inorganic chlorine at constant pH
- Measuring range 0 – 0.5 ppm/ 0 – 2 ppm/ 0 – 5 ppm/
- 0 – 10 ppm/ 0 – 200 ppm
- pH range 6 – 8
- Pressure range 0 – 1 bar
Free inorganic chlorine with reduced pH-dependence
- Measuring range 0 – 2 ppm/ 0 – 10 ppm
- pH range 4 – 9
- Pressure range 0 – 3 bar
Free chlorine on the basis of iso-cyanuric acid (organic free chlorine)
- Measuring range 0 – 2 ppm/ 0 – 5 ppm/ 0 – 10 ppm
- pH range 4 – 12
- Pressure range 0 – 0.5 bar
- Process temperature 0 – 45° C
- Flow rate range approx. 30 l/h
- Body material PVC-U, PEEK, SS 1.4571 ; Electrode Silver chloride with gold ; Membrane PTFE
- Cable not included ; Connection 2-pole terminal
FCL HP
- Measuring range 0 – 1 ppm/ 0 – 5 ppm/ 0 – 10 ppm
- pH range 1 – 9
- Process temperature 0 – 50° C/ 0 – 70° C
- Pressure range 0 – 8 bar
- Flow rate range approx. 30 l/h
- Body material PVC-U, PEEK ; Electrode Gold ; Membrane PTFE
- Cable not included ; Connection 2-pole terminal
DCL
- Measuring range 0 – 2 ppm/ 0 – 10 ppm
- pH range 1 – 11
- Process temperature 0 – 45° C
- Pressure range 0 – 1 bar
- Flow rate range approx. 30 l/h
- Body material PVC-U ; Electrode Gold ; Membrane PTFE
DCL HP
- Cable not included ; Connection 2-pole terminal
- Measuring range 0 – 1 ppm
- pH range 1 – 9
- Process temperature 0 – 50° C/ 0 – 70° C
- Pressure range 0 – 5 bar/ 0 – 8 bar
- Flow rate range approx. 30 l/h
- Body material PVC-U, PEEK ; Electrode Gold ; Membrane PTFE
- Cable not included ; Connection 2-pole termin
TCL
- Measuring range 0 – 2 ppm/ 0 – 5 ppm/ 0 – 10 ppm
- pH range 4 – 12 (linear decrease with approx. 5 % per increasing pH-unit)
- Process temperature 0 – 45° C
- Pressure range 0.5 bar
- Flow rate range approx. 30 l/h
- Body material PVC-U, PEEK, SS 1.4571 ; Electrode Silver chloride with gold ; Membrane PTFE
- Cable not included ; Connection 2-pole terminal
