Precise measurement of water-quality parameters
Overview
Dissolved Oxygen (DO) is the amount of oxygen dissolved in a unit of water. Oxygen gets into water by: diffusing within the
surrounding air, aeration (turbulent movement), and as a waste product from plants through photosynthesis. Galvanic DO sensors consist of two electrodes: an anode and cathode. Both of these electrodes are immersed in electrolytes (inside the sensor body).
Oxysens®
measures the electric current influenced by the oxygen partial pressure. It offers high accuracy but requires a flow rate ≥ 0.03 m/s and
voltage signal output. It is suitable for fish farming and biological treatment plants.
S423C OPT
Optical measure using luminescence. Offers high accuracy, and comes with an RS 485 modbus RTU Protocol communication output
Suitable for waste water, sludge treatment, fish farming, biological treatment plants.
S423C OPT PVC
Optical measure using luminescence, offering high accuracy. Comes with a 4 – 20 mA output. It is suitable for waste water, sludge treatment, fish farming, biological treatment plants.
surrounding air, aeration (turbulent movement), and as a waste product from plants through photosynthesis. Galvanic DO sensors consist of two electrodes: an anode and cathode. Both of these electrodes are immersed in electrolytes (inside the sensor body).
Oxysens®
measures the electric current influenced by the oxygen partial pressure. It offers high accuracy but requires a flow rate ≥ 0.03 m/s and
voltage signal output. It is suitable for fish farming and biological treatment plants.
S423C OPT
Optical measure using luminescence. Offers high accuracy, and comes with an RS 485 modbus RTU Protocol communication output
Suitable for waste water, sludge treatment, fish farming, biological treatment plants.
S423C OPT PVC
Optical measure using luminescence, offering high accuracy. Comes with a 4 – 20 mA output. It is suitable for waste water, sludge treatment, fish farming, biological treatment plants.
Features
Oxysens®
- Measuring range 40 ppb – 40 ppm
- Response time t98% < 60 s at 25 °C, from air to nitrogen
- Temperature compensation with internal NTC 22 kOhm
- Process temperature 0 – 60 °C
- Pressure range (relative to ambient) 0 – 4 Bar
- Wetted Parts SS 1.4435, Silicone, EPDm, PEEK ; Electrode Silver- Platinum combination
- Membrane delivered with Optiflow
- Electrolyte Alkaline solution
- Cable 5 meter
- Mechanical connection PG13.5
S423C OPT
- Measuring range 0 – 20 ppm
- Response time t90% < 60 s
- Temperature compensation with internal NTC probe
- Process temperature 0 – 60 °C
- Pressure range (relative to ambient) 0 – 5 Bar
- Body material SS316 ; Electrodes material special optical glasses ; O-Rings NBR and Silicon
- Cable 10 meter
- Mechanical connection 33 mm
S423C OPT PVC
- Measuring range 0 – 20 ppm
- Response time t90% < 60 s
- Temperature compensation with internal NTC probe
- Process temperature 0 – 60 °C
- Pressure range (relative to ambient) 0 – 5 Bar
- Body material PVC ; Electrodes material special optical glasses ; O-Rings NBR and Silicon
- Cable 10 meter
- Mechanical connection 33 mm
